20Y2600151 20Y2600150 20Y2600153 20Y2600152 Excavator Swing Machinery Gear Used For Komatsu PC200-6 PC210-6

20Y-26-00151 20Y-260-0150 20Y-26-00153 20Y-26-00152 PC200-6 swing gearbox PC220-6 swing gearbox PC228US-2 swing gearbox

• 20Y2600151 20Y2600150 20Y2600153 20Y2600152 Excavator Swing Machinery Gear Used For Komatsu PC200-6 PC210-6

• Description

The Swing drive reducer gearbox rotates the top of the Excavator on the chassis together with the slewing gear bearing.

Attributes: Heavy Duty Swing Drives are designed to be rebuilt and reused. The below following gear components are included in swing drive: sun gear, planetary gear, needle bearing, roller bearing, carrier, pinion shaft, pinion gear, oil seal, ring gear, swing housing .

• Spec Sheet

In a Komatsu PC200-6 excavator, the swing machinery gearbox is an integral part of the swing machinery system. It is responsible for transmitting and converting power from the swing motor to the swing gear, enabling the rotation of the upper structure.

Here are some key points about the swing machinery gearbox in a Komatsu PC200-6 excavator:

Function: The swing machinery gearbox is designed to provide the necessary gear reduction and torque multiplication to drive the swing gear and rotate the upper structure of the excavator smoothly and efficiently.

Gear Reduction: The gearbox utilizes a combination of gears, including spur gears, helical gears, or planetary gears, to reduce the high-speed input from the swing motor and increase torque output to drive the swing gear.

Lubrication: The swing machinery gearbox requires proper lubrication to ensure smooth operation and longevity. Lubricating oil or grease is used to minimize friction and reduce wear between the gears and other moving components within the gearbox.

Sealing: The gearbox is typically equipped with seals and gaskets to prevent oil leakage and to protect it from external contaminants, such as dust, dirt, and moisture, which could potentially cause damage to the gearbox components.

Maintenance and Inspection: Regular maintenance and inspection of the swing machinery gearbox are essential to identify and address any signs of wear, damage, or lubrication issues. This helps ensure the proper functioning of the swing machinery system and extends the overall lifespan of the excavator.

It is important to note that specific details and configurations of the swing machinery gearbox can vary depending on the exact model and specifications of the Komatsu PC200-6 excavator. For accurate and detailed information regarding the swing machinery gearbox in a specific Komatsu PC200-6 excavator, it is recommended to consult the manufacturer's documentation or contact Komatsu directly.

• Parts Diagram

20Y-26-00151[1]- SWING MACHINERY A. Komatsu ["SN: 102083-UP"] ancatalogs:["20Y2600150"] |$0. Weight: 190 kg.

20Y-26-00150[1]- SWING MACHINERY A. Komatsu ["SN: 96514-102082"] ancatalogs:["20Y2600151"] |$1. Weight: 190 kg.

1.20Y-26-22210[1]- Komatsu ["SN: 96514-UP"] ancatalogs:[] Weight: 76 kg.

2.20Y-26-22330[1]- BEARING Komatsu China ["SN: 96514-UP"] ancatalogs:["20Y2622331", "20Y2622430"] Weight: 3.28 kg.

3.20Y-26-22340[1]- BEARING Komatsu China ["SN: 96514-UP"] ancatalogs:["20Y2622342", "20Y2622440"] Weight: 9.6 kg.

4.20Y-26-22191[1]- COVER Komatsu ["SN: 97767-UP"] ancatalogs:["20Y2622190"] Weight: 4.6 kg.

4.20Y-26-22190[1]- COVER Komatsu ["SN: 96514-97766"] ancatalogs:["20Y2622191"] Weight: 4.6 kg.

5.01010-81045[12]- BOLT Komatsu ["SN: 96514-UP"] ancatalogs:["0101051045", "01010D1045"] Weight: 0.039 kg.

6.01643-31032[12]- WASHER Komatsu ["SN: 80001-UP"] ancatalogs:["802150510", "0164331030", "0164381032", "0164371032", "0164331022", "0164321032", "0164301032", "6127212530", "802170002", "R0164331032"] Weight: 0.054 kg.

7.20Y-26-22420[1]- SEAL Komatsu China ["SN: 97767-UP"] ancatalogs:[] Weight: 0.3 kg.

7.07012-00125[1]- SEAL Komatsu China ["SN: 80001-97766"] ancatalogs:[] Weight: 0.142 kg.

[-1]- (20Y-26-22420,20Y-26-22191) |$$12.

8.20Y-26-21141[1]- SHAFT, 15 TEETH Komatsu OEM ["SN: 96514-UP"] ancatalogs:["20Y2621140", "20Y2621142"] Weight: 35 kg.

9.20Y-26-22170[1]- CARRIER Komatsu ["SN: 96514-UP"] ancatalogs:[] Weight: 8.55 kg.

10.20Y-26-22141[4]- GEAR, 36 TEETH Komatsu China ["SN: 97709-UP"] ancatalogs:["20Y2622140"] Weight: 1.8 kg.

10.20Y-26-22140[4]- GEAR, 36 TEETH Komatsu China ["SN: 96514-97708"] ancatalogs:["20Y2622141"] Weight: 1.8 kg.

11.20G-26-11240[4]- BEARING Komatsu China ["SN: 96514-UP"] ancatalogs:["20G2611241", "20G2611410"] Weight: 0.24 kg.

12.20Y-27-21240[8]- WASHER Komatsu China ["SN: 96514-UP"] ancatalogs:[] Weight: 0.02 kg.

13.20Y-26-22250[4]- PIN Komatsu China ["SN: 96514-UP"] ancatalogs:[] Weight: 0.52 kg.

14.20Y-27-21280[4]- PIN Komatsu China ["SN: 96514-UP"] ancatalogs:[] Weight: 0.01 kg.

15.20Y-26-21240[1]- PLATE Komatsu ["SN: 80001-UP"] ancatalogs:[] Weight: 5.1 kg.

16.112-32-11211[1]- BOLT Komatsu ["SN: 80001-UP"] ancatalogs:[] Weight: 0.09 kg.

17.20Y-26-22151[1]- GEAR, 101 TEETH Komatsu ["SN: 102083-UP"] ancatalogs:["20Y2622150"] Weight: 18.8 kg.

17.20Y-26-22150[1]- GEAR, 101 TEETH Komatsu ["SN: 96514-102082"] ancatalogs:["20Y2622151"] Weight: 18.8 kg.

18.20Y-26-22131[1]- GEAR, 27 TEETH Komatsu ["SN: 97709-UP"] ancatalogs:["20Y2622130"] Weight: 2.15 kg.

18.20Y-26-22130[1]- GEAR, 27 TEETH Komatsu ["SN: 96514-97708"] ancatalogs:["20Y2622131"] Weight: 2.15 kg.

19.04064-07525[1]- RING Komatsu ["SN: 96514-UP"] ancatalogs:[] Weight: 0.026 kg.

20.20Y-26-22220[1]- THRUST WASHER Komatsu ["SN: 96514-UP"] ancatalogs:[] Weight: 0.04 kg.

21.20Y-26-22160[1]- CARRIER Komatsu ["SN: 96514-UP"] ancatalogs:[] Weight: 5.1 kg.

22.20Y-26-22120[3]- GEAR, 39 TEETH Komatsu China ["SN: 96514-UP"] ancatalogs:[] Weight: 1.25 kg.

23.20Y-26-21281[3]- BEARING Komatsu ["SN: 110071-UP"] ancatalogs:["20Y2621280", "20X2621240", "20Y2621510"] Weight: 0.1 kg.

23.20Y-26-21280[3]- BEARING Komatsu ["SN: 80001-110070"] ancatalogs:["20Y2621281", "20X2621240", "20Y2621510"] Weight: 0.1 kg.

25.20Y-26-22240[3]- PIN Komatsu ["SN: 96514-UP"] ancatalogs:[] Weight: 0.367 kg.

27.20Y-26-22110[1]- GEAR, 22 TEETH Komatsu ["SN: 96514-UP"] ancatalogs:[] Weight: 0.4 kg.

28.20Y-26-22230[1]- THRUST WASHER Komatsu ["SN: 96514-UP"] ancatalogs:[] Weight: 0.1 kg.

29.20Y-26-22410[1]- COVER Komatsu China ["SN: 96514-UP"] ancatalogs:[]

30.01011-81450[4]- BOLT Komatsu China ["SN: 96514-UP"] ancatalogs:[]

31.01643-31445[4]- WASHER Komatsu ["SN: 96514-UP"] ancatalogs:["0164301432"] Weight: 0.019 kg.

32.07042-30617[1]- PLUG Komatsu China ["SN: 96514-UP"] ancatalogs:[]

33.07042-30108[1]- PLUG Komatsu ["SN: 96514-UP"] ancatalogs:["0704220108"] Weight: 0.008 kg.

34.07042-30415[1]- PLUG Komatsu ["SN: 96514-UP"] ancatalogs:[] Weight: 0.056 kg.

• Advantage

1. The gear parts are built to fit to the genuine drive gearbox system.

2. The gear parts are supplied strictly according to the genuine parts catalog.

3. All the gear components are manufactured from carefully selected materials with standard quality using standard production process heat treatment processes — including carburizing, nitriding, and induction hardening.

4. Surplus stock and the various varioties of gear parts that cover final and swign drive for upto 70 Tons excavator. HITACHI KOMATSU HYUNDAI Vo-lvo DOOSAN KOBELCO SUMITOMO KATO JCB

• Warranty

1. Warranty Period: 3 Months' warranty from the date of arrival. Longer period of 6 months' warranty could be offered with higher price level.

2. Warranty type: replacement of the parts that have quality problem.

3. Warranty is not valid for below s

* Cutomer give wrong information about the order

* Force Majeure

* Wrong installation and operation

* rust

• Packing & Delivery

* Strong carton or wooden box for gear components. Wooden box for gearbox assembly

* Delivery methods: By Sea, By air to local internation airport, By express like DHL TNT FEDEX
